SK hynix and foundries advance hybrid bonding for AI silicon in 2027

SK hynix and rival foundries accelerated deployment plans for direct copper hybrid bonding on Sept. 10, 2026, realigning advanced packaging roadmaps as artificial intelligence memory stacks encounter physical thermal ceilings.

Hybrid bonding eliminates solder microbumps by joining copper pads directly under heat and pressure. The process establishes vertical electrical connections between stacked dies without using intervening solder spheres or adhesive underfill resins.

The copper-to-copper interconnect cuts package thermal resistance by 35% and allows memory core die thickness to expand by 24%, according to engineering disclosures SK hynix released ahead of industry review sessions.

Eliminating microbumps permits through-silicon via pitch to contract below 18 micrometers. That spacing provides the wiring density needed to link high-bandwidth memory stacks to graphic processors without consuming additional circuit board area.

Memory suppliers face severe heat accumulation at the top of 16-layer dynamic random-access memory cubes. Signal bandwidth nearly doubles every two memory generations, driving a 2.2-fold increase in packaging thermal stress.

The Joint Electron Device Engineering Council, the global microelectronics standards group, relaxed structural pressure earlier this year. The council raised the maximum permitted memory stack height from 720 micrometers to 775 micrometers.

That dimensional relief allowed memory producers to postpone immediate capital spending on hybrid bonding. Taiwan Semiconductor Manufacturing Company responded by directing its materials and equipment suppliers to prolong the operating life of solder microbumps.

TSMC asked South Korean and Japanese supply partners to shrink microbump heights from 10 micrometers down to five micrometers. The foundry aims to qualify five-micrometer microbumps for mass production in late 2027.

Current high-bandwidth memory, known as HBM3E, uses microbumps measuring between 15 and 25 micrometers in height. Japanese materials vendors warned customer procurement teams that maintaining structural stability below 15 micrometers requires new underfill chemistry.

TSMC deferred volume hybrid bonding adoption in high-bandwidth memory lines until the later stages of HBM4 or early HBM5 production. The foundry already runs hybrid bonding on its System-on-Integrated-Chips logic platform.

SK hynix maintained its proprietary mass reflow-molded underfill assembly through upcoming HBM4 and HBM4E production cycles. The memory maker pushed full commercial hybrid bonding deployment out to 20-high HBM5 stacks arriving by 2029.

SK hynix ordered an inline hybrid bonding development line pairing Applied Materials chemical mechanical planarization tools with BE Semiconductor Industries bonders. The equipment system carried an estimated value of 20 billion won ($15 million).

The South Korean memory producer also expanded hybrid bonding application beyond dynamic memory. SK hynix plans to complete hybrid bonding development for 400-layer NAND flash memory in 2026, targeting mass production in 2027.

Samsung Electronics detailed a competing advanced packaging architecture during the SEMICON Taiwan conference in Taipei. The company introduced its CUBE framework, focusing on capacity, utilization, bandwidth as well as power and thermal efficiency.

Samsung targets a 20% reduction in thermal resistance and a 20% gain in power efficiency for HBM5 over previous standards. The company will manufacture the underlying base logic die using its two-nanometer foundry node.

Samsung adopted heat path blocks as an interim thermal solution to cool 16-layer stacks before deploying full copper bonding. The metal blocks dissipate concentrated heat generated by high-frequency switching across dense through-silicon via arrays.

Samsung also revealed development targets for zHBM, an architecture that mounts memory stacks directly on top of graphics processors. The direct vertical configuration aims to reduce thermal resistance by 75% to 90%.

Tokyo Electron introduced dedicated hybrid bonding platforms at SEMICON Taiwan to address 16-layer memory assemblies. The tools integrate wafer surface plasma activation, chemical cleaning and high-temperature thermal annealing chambers.

Tokyo Electron budgeted 500 billion yen ($3.5 billion) in cumulative bonding tool sales through 2030, according to its investor presentations. The Japanese toolmaker expects hybrid bonding to capture significant packaging capital expenditure.

Intel Foundry expanded customer outreach for its embedded multi-die interconnect bridge packaging as an alternative assembly channel. Intel EMIB-T bridges incorporate through-silicon vias to deliver vertical power directly through stacked high-bandwidth memory packages.

Using embedded bridge packaging reduces interposer-related assembly expenses by up to 50% compared with conventional silicon interposers, industry cost analyses show. SK hynix evaluated Intel packaging compatibility alongside TSMC CoWoS lines.

Foundries and memory manufacturers have not published a joint qualification timeline, and TSMC has not released certified yield targets for its five-micrometer microbump lines, commercial disclosures show.

Material suppliers target the second half of 2027 to deliver five-micrometer microbump samples, while toolmakers schedule commercial hybrid bonding shipments ahead of qualification runs ending Dec. 31, 2027.
